BMDO 80 CS

Bandsawing Machine

BMDO 80 CS

Optional Features

Standard Features

Product Description

~~Performance



Vertical Slide for maximum cutting power and rigidity

Standard with Speed Inverter for speeds of 20-100 m/min.

Electric Servo Feeding for +/- 0.05 ~ 0.1mm Cutting Length precision (per stroke)

Capacity up to 80mm in Tube and Solid Bars

Superior Gear Box design for maximum machine life and performance

Flexible Gripper Feeding + Floating Carriage allow for maximum feeding precision even in material which is not perfectly straight

Cutting Examples



.D. 50mm solid bar, L = 100mm, cycle time is 20sec

–         O.D. 75mm solid bar, L = 50mm, cycle time is 31sec



Intuitive and User Friendly Interface with Touch Screen system

Ability to program multiple cutting lengths per bar

Safety Covers  for maximum operator protection and comfort



Head for ferrous material not with endless screw, but with cemented and ground helical gear for obtaining a high operating rate  without any play or vibration of the saw-blade. Head with inverter allowing a continuous change of the cutting speed



Technical Details



PARAMETER UNIT UNIT
Round Cutting Capacity mm 20-80
Clamp Max Opening mm 85
Feed Lenght mm 500
Main Drive Motor kW 5,5
Hydraulic Motor kW 1,5
Feeder Servo Motor Kw 1
Chip Conveyor Motoru kW 0,25
Coolant Pump kW 0,2
Cutting Speeds m/min. 20-100
Band Dimensions mm 260 - 350  2.0t - 3.0t (max)
Working Height mm 900
Weight Kg 1425
Length mm 1600
Width mm 1700
Height mm 2100
