BMSY-1113C

Bandsawing Machine

Product Description

Beka-Mak Twin-Pillar horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. These models can cope with most types of material.Blade guides with rollers and carbide pads provide precise support for the blade. Thermal overload and no-volt release are standart feature and the machines automatically switch off at the end of the cut and sawframe is lifted hydraulically up to the adjusted level.



Technical Details



PARAMETER UNIT UNIT
Height mm 2975
Width mm 1500
Length mm 5300
Weight kg 11390
Working Height mm 545
Band Dimensions mm 10900x67x1,6
Cutting Speeds m/min. 20 - 100
Chip Conveyor Motor kW 0.25
Coolant Pump kW 0.20
Hydraulic Motor kW 7.5
Main Drive Motor kW 11
Square Cutting Capacity mm 1110
Flat Cutting Capacity mm 1110 x 1300
Round Cutting Capacity mm 1110
