BMSY-460C

Bandsawing Machine

Product Description

Beka-Mak Linear Way horizontal bandsaws have been designed to give a low cost compact and rugged machines.The bow is constructed in heavy gauge steel and mounted two chromed and grinding pillars offer a strong rigid sawframe, providing a high degree of accurancy when cutting. The machines are fitted with a removable coolant tank incorporating a submerged electric coolant pump which supplies coolant to both guide assemblies. These models can cope with most types of material.Blade guides with rollers and carbide pads provide precise support for the blade. Thermal overload and no-volt release are standart feature and the machines automatically switch off at the end of the cut and sawframe is lifted hydraulically up to the adjusted level. Bi-Metal sawblade and 1,2 meter infeed roller table are supplied as standart.



Technical Details



PARAMETER UNIT UNIT
Round Cutting Capacity mm 460
Flat Cutting Capacity mm 650 x 460
Square Cutting Capacity mm 460
+45° Round Cutting Capacity mm 380
+45° Flat Cutting Capacity mm 380 x 460
+45° Square Cutting Capacity mm 380
Main Drive Motor kW 4
Hydraulic Motor kW 0,55
Coolant Pump kW 0,12
Cutting Speeds m/min. 20 - 100
Band Dimensions mm 5200x41x1,3
Working Height mm 590
Weight kg 1520
Lenght mm 3100
Width mm 1000
Height mm 1800
