BMSO-320GLS NC
Optional Features
Product Description
GLS modei is the ideal model for mass production and bundle cutting of solid material, tube and profile. Angular cutting is available between 90-30° degrees. Servo feeding system with bal screw reduces cutting tolerances to zero error marning. Omron brand user friendly color touch screen PLC control panel allows to save 30 different cutting programsthat each can have 50 cutting steps. Hydraulic top clamping and hexagonal vices are also available for bundle cutting.
Technical Details
| PARAMETER | UNIT | UNIT |
|---|---|---|
| Round Cutting Capacity | mm | 320 |
| Flat Cutting Capacity | mm | 610 x 320 |
| Square Cutting Capacity | mm | 320 |
| -60° Round Cutting Capacity | mm | 320 |
| -60° Flat Cutting Capacity | mm | 510 x 320 |
| -60° Square Cutting Capacity | mm | 320 |
| -45 Round Cutting Capacity | mm | 320 |
| -45° Flat Cutting Capacity | mm | 355 x 320 |
| -45° Square Cutting Capacity | mm | 320 |
| -30° Round Cutting Capacity | mm | 260 |
| -30° Flat Cutting Capacity | mm | 280 x 200 |
| -30° Square Cutting Capacity | mm | 225 |
| Main Drive Motor | kW | 2,2 |
| Hydraulic Motor | kW | 1,1 |
| Coolant Pump | kW | 0,12 |
| Cutting Speeds | m/min. | 20 - 100 |
| Band Dimensions | mm | 4160x34x1,1 |
| Working Height | mm | 740 |
| Weight | kg | 2060 |
| Length | mm | 2300 |
| Width | mm | 2350 |
| Height | mm | 1750 |
