BMSO-320S
BMSI 320S is designed to maximize our customers' production of metal, profile and pipe cuts in high-volume units with a fully automatic servo feeding system.
CHARACTERISTICS
-User friendly Omron touch screen.
- Ability to save up to 30 different cutting lenght steps in 50 different programs.
-Servo feeding with 700mm stroke. 9.999mm multiple stroke.
|
|||||||||||
| Main Drive Motor | 2,2 kW | ||||||||||
| Hydraulic Motor | 1,5 kW | ||||||||||
| Coolant Pump | 0,12 kW | ||||||||||
| Servo Motor | 1 kW | ||||||||||
| Blade Speed | 15-120 m/min | ||||||||||
| Blade Dimensions | 4160x34x1,1 mm | ||||||||||
| Working Height | 850 mm | ||||||||||
| Weight | 1900 kg | ||||||||||
| Lenght | 1950 mm | ||||||||||
| Width | 2150 mm | ||||||||||
| Height | 1800 mm | ||||||||||
